一、應用和特點
XZNZDJ制氮機廣泛應用于食品工業、包裝、儲藏保鮮、酒類封裝和保存以及醫藥、電子、煤礦、石油等業。該設備運行成本低、結構簡單、占地面積小、安全可靠、操作方便、回收率高等特點。
二、工作原理
本設備采用PSA變壓吸附原理，利用碳分子篩在壓力變化時具有分離空氣中氮的能力，以空氣為原料，將壓縮空氣經除油、干燥、過濾等凈化處理后，送入雙塔組成的吸附組件，壓縮空氣在塔內經過壓吸附后產生氮?dú)?，而另一塔在解吸再生，兩塔交替循環，即可不斷地得到純度為98-99.9%的廉價氮?dú)狻?/p>
三、設備組成
本設備由空氣氣源凈化及純化兩大部分組成?？諝鈿庠磧艋梢韵聨讉€(gè)單元組成；冷凍干燥單元，除油單元、吸咐單元、空氣緩沖罐單元。空氣純化由變壓吸咐單元和氮?dú)饩彌_單元組成。該設備主要用于從空氣中分離出廉價的氮?dú)?，以供使用?/p>
四、流程簡述
由無油壓縮機提供的穩定壓縮空氣氣源經冷干機被除去壓縮空氣中大部分水和部分油霧，經除油器除去微量油份和水，再經無油再生干燥器進行深度脫水，經過濾器得到干燥的、潔凈的壓縮空氣貯存于空氣緩沖罐中，然后，干燥的空氣經變壓吸咐器，空氣中的氧氣和二氧化碳被碳分子篩吸咐，經吸咐器純化后，得到氮?dú)?，?jīng)過濾器得到較潔凈的氮?dú)膺M(jìn)入氮?dú)饩彌_罐以備使用?？匮鮾x可在線檢測出氮?dú)庵械难鹾?。從而得到氮?dú)獾募兌?。氮?dú)饩彌_罐中的氮?dú)饨?jīng)減壓閥及流量計輸出以供用戶使用。
該設備具有工藝流程簡單，操作簡便，結構緊湊，占地面積?。怀涸偕?，節能顯著，制氮成本低，系統聯鎖，安全可靠等特點。該設備是一種理想的小型制氮空分設備，廣泛應用于啤酒、飲料、食品、水果的充氮包裝及儲藏、石油化工、冶金、熱處理、醫藥、電子等行業。
1.Application and Features
XZNZDJ nitrogen generator is widely used in the food industry, packaging, storage and preservation, wine packaging and preservation, as well as pharmaceutical, electronics, coal mining, petroleum and other industries. The device has the characteristics of low operating cost, simple structure, small footprint, safety and reliability, easy operation, and high recovery rate.
2.Working principle
This equipment adopts the principle of PSA pressure swing adsorption, utilizing the ability of carbon molecular sieves to separate nitrogen from air under pressure changes. Using air as raw material, compressed air is purified through processes such as oil removal, drying, and filtration before being sent to the adsorption component composed of two towers. The compressed air undergoes overpressure adsorption in the tower to produce nitrogen gas, while the other tower undergoes desorption and regeneration. The two towers alternate and continuously obtain cheap nitrogen gas with a purity of 98-99.9%.
3、 Equipment composition
This device consists of two main parts: air source purification and purification. Air source purification consists of the following units:; Freeze drying unit, oil removal unit, adsorption unit, air buffer tank unit. Air purification consists of a pressure swing adsorption unit and a nitrogen buffer unit. This device is mainly used to separate inexpensive nitrogen from the air for use.
4、 Process description
The stable compressed air source provided by the oil-free compressor is removed from most of the water and some of the oil mist in the compressed air by a cold dryer, and then removed from trace amounts of oil and water by an oil remover. It is then deeply dehydrated by an oil-free regeneration dryer and filtered to obtain dry and clean compressed air, which is stored in an air buffer tank. Then, the dried air is passed through a pressure swing absorber, and the oxygen and carbon dioxide in the air are adsorbed by carbon molecular sieves. After purification by the absorber, nitrogen gas is obtained, which is filtered to obtain relatively clean nitrogen gas and enters the nitrogen buffer tank for use. The oxygen controller can detect the oxygen content in nitrogen online. Thus obtaining the purity of nitrogen gas. The nitrogen in the nitrogen buffer tank is output through a pressure reducing valve and flow meter for user use.
This device has a simple process flow, easy operation, compact structure, and small footprint; Atmospheric regeneration, significant energy saving, low nitrogen production cost, system interlocking, safety and reliability. This device is an ideal small-scale nitrogen air separation equipment, widely used in nitrogen filling packaging and storage of beer, beverages, food, fruits, petrochemicals, metallurgy, heat treatment, pharmaceuticals, electronics and other industries.
